SC APC Shutter Fiber Optic Adapter Singlemode Duplex with Anti laser shutter flanged

Name: SC APC Shutter Fiber Optic Adapter Singlemode Duplex with Anti laser shutter flanged
Brand: Gorelink Communication (Shenzhen) Co., Ltd.
SKU: G419-441A
Availability: InStock

Brand Name:	GoreLink
Model Number:	G419-441A
MOQ:	1pc
Delivery Time:	1-3 Working days
Payment Terms:	T/T, Western Union,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product:

Fiber Optic Adapter

Application:

FTTX/Telecommunication

Laser Protection:

With Anti-laser Shutter

Part No.:

G419-441A

Adapter Type:

LC/UPC

Fiber Count:

Quad

Fiber Type:

Singlemode

Wavelength:

1310nm

Color:

Blue

Flange:

Without Flange

Insertion Loss:

≤0.3dB

Return Loss:

≥60dB

Sleeve:

Zirconia

Housing Material:

Plastic

Operating Temperature:

-40~+75℃

Storage Temperature:

- 40~+85℃

Packaging Details:

25pcs/Pkt

Highlight:

SC APC fiber optic adapter

singlemode duplex fiber adapter

flanged anti laser shutter adapter

Product Description

SC APC Shutter Fiber Optic Adapter Singlemode Duplex with Anti laser shutter flanged

This LC UPC quad fiber adapter is a high-density, multi-fiber optical terminator designed to safely and simultaneously terminate four independent laser outputs. It is engineered for use with LC Quad (4-fiber MPO-based) trunk systems commonly found in modern high-speed data centers (40G/100G/400G Ethernet), central offices, and any environment using parallel optics. This device ensures laser safety, protects sensitive transceivers from back-reflection, and maintains network integrity.

Application

FTTH access network
Telecommunication Networks
CCTV Networks
Data Center
Local Area Networks

General Specification

Fiber Adapter Type	SC
Body Style	Duplex
Fiber Mode	Singlemode
Polish Type	APC
Insertion Loss	≤0.3dB
Mounting Type	With Flange
Housing Color	Blue
Durability	＞1000 times
Alignment Sleeve Material	Ceramic
Flammability Rate	UL94-V0
Compliant	Telcordia GR-326-CORE

Ordering Information

PART NO.	DESCRIPTION
G419-441A	Fiber Optic Adapter, Anti Laser SC/APC Singlemode Duplex with flange

If you need any further assistance, please feel free to contact us at sales@gorelink.com.
